There are other possibilities than the VP status/pedal position message in order to control the engine speed. Torque speed control - TSC1 (0C 00 00 03/11/E6) The TSC1 message has priority over the pedal position that is sent with the VP status message.
The battery plus and minus in the EIC is connected to the battery via the starter motor. I.e. these pins in the EIC are outputs that are intended to power other CAN nodes connected to the engine CAN network. Failure to do this can cause EECU damages.
It is possible to read and adjust parameters with the VODIA tool, part no.3838619, as described in the following pages. The VODIA tool is connected to the diagnostics socket, a 6-pin connector; refer to VODIA user instructions for instructions.
• The installation must be prepared for well and carried out with the greatest care. • Secure the connecting cable between the engine and instrument panel with clamps. Bear in mind that connector blocks must be mechanically secured so that they are not exposed to any pulling forces.
