This instruction manual is intended only for professional use. Read the instructions carefully before starting the installation. If the installation is performed in an incorrect manner, it may cause personal injury or damage to property and machinery. Ask your Volvo Penta dealer for help if there is anything in this manual that you do not understand or are uncertain about.
1 Remove the left fan cowl; refer to 26-3, Fan, change. 2 Remove the alternator drive belt; refer to Drive Belt, Change page 204. 3 Undo the alternator cable connections: • Terminal W • Terminal D+ • Terminal B+ 4 Remove the harness clamp from the alternator. 5 Remove the alternator.
1 Cooling system drained; refer to Coolant, Change page 187. 2 Remove the fan cowls; refer to 26-3, Fan, change. 3 Remove the fan; refer to 26-3, Fan, change. 4 Remove the fuel pump and coolant pump drive belt; refer to Drive Belt, Change page 204. 5 Remove the thermostat housing according to 26-2, Thermostat Housing, Change. 6 Unbolt (1) the pulley.
Connect 9996666 Nipple and 9998339 Manometer. Where necessary, 9998493 Hose may be used between the nipple and the manometer. Test run the engine at full load in order to check max boost air pressure.
