Reliability of Fushchuang FPSS8607-G50 Parallel Intelligent Terminal 1

The reliability of the Fushchuang FPSS8607-G50 parallel intelligent terminal is as follows:

1. Utilizing a 32-bit ARM microcontroller and dual chip processing, with high hardware integration and accurate data, and the ability to build a gateway to the cloud;

2. The 7-inch LCD display is 1024 * 600, providing more direct graphical data display. Iconic display of functions, making it easy to turn on and off functions at a glance. Chinese and English languages are optional, and can be directly operated on the interface;

3. Using silicone buttons, it has strong adaptability to high and low temperatures in the environment, effectively waterproof and oil resistant. The buttons are made of high elastic materials, providing a better feel;

4. It has two RS485 communication interfaces and can be configured separately on the panel for flexible use. The MODBUS protocol can be used to achieve the "three remote" function;

5. Equipped with a CANBUS interface, it can be connected to an electronic fuel injection machine with J1939. It can not only monitor common data of the electronic fuel injection machine (such as water temperature, oil pressure, speed, etc.), but also control speed increase and decrease through the CANBUS interface;

6. Suitable for three-phase four wire, three-phase three wire, single-phase two wire, two-phase three wire (120/240V) power supply 50/60Hz systems;

7. Collect and display three-phase voltage, three-phase current, frequency, and power parameters of the busbar/generator;

8. Equipped with waveform display of power generation voltage and total harmonic distortion rate;

9. The busbar has the function of detecting phase loss and reverse phase sequence, while the power generation has the function of detecting overvoltage, undervoltage, overvoltage, underfrequency, overcurrent, high unbalanced current, low power factor, overvoltage, reverse power, demagnetization, phase loss, and reverse phase sequence;

10. The synchronization parameters include: voltage difference between power generation and busbar, frequency difference between power generation and busbar, and phase angle difference between power generation and busbar;

11. The automatic mode has multiple working modes, which can be selected whether to carry load, and whether to start all or start according to demand;

12. Capable of soft load transfer during parallel/disconnection;

13. It has 10 analog input ports, with a variety of types, including 4 for resistance type, 3 for current type, and 3 for voltage type; The default settings include water temperature, oil pressure, fuel level, and oil temperature, and the interface can be flexibly set;

Dingbo Power has advanced testing equipment, modern production technology, professional manufacturing technology, perfect quality management system, and strong technical research and development capabilities. It can provide 3KW～2500KW various specifications of ordinary, automatic, four protection, automatic switching, low noise and mobile generator sets, high quality and low energy consumption to meet the diverse power needs of customers, and can also meet users with different voltages and different frequencies. It is required to create a parallel power supply system for multiple units. If you are interested in our product or any question on generator, welcome to send email to sales@dieselgeneratortech.com.
