Operation Safety of Excitation System for Diesel Generator Sets

Do you know how to manage the operation safety of the excitation system of diesel generator sets? The excitation system of grid connected units should operate in automatic mode. If the excitation system malfunctions or needs to exit the automatic mode for testing, it must be reported to the dispatch department in a timely manner. When the automatic channel of the excitation regulator malfunctions, it should be promptly repaired and put into operation. It is strictly prohibited for the generator to operate for a long time under manual excitation regulation (including closed-loop regulation based on the magnetic field current of the generator or AC exciter). During manual excitation regulation operation, when adjusting the active load of the diesel generator, the reactive load of the generator must be appropriately adjusted to prevent the diesel generator from losing static stability.

The excitation regulator of the diesel generator in phase leading operation should be put into automatic mode, and the low excitation limiter must be put into operation. The limits and protection settings of the excitation system should be within the allowable range for safe operation of the generator and regularly verified. When using Automatic Voltage Control (AVC) to regulate the voltage of the generator, the excitation system of the controlled diesel generator set should be put into automatic mode. Strengthen the daily inspection of excitation system equipment, and the inspection content should at least include that the temperature of each component of the excitation transformer should be within the allowable range, the current sharing coefficient of the rectifier cabinet should not be less than 0.9, the temperature should be normal, and the ventilation hole filter screen should not be blocked. The wear of the carbon brush of the generator or exciter rotor is within the allowable range, and the slip ring spark does not affect the normal operation of the diesel generator set.
