Reasons for Inability to Charge The Daewoo Generator Set

The reason for excessive oil consumption of Daewoo diesel generator set is that the clearance of oil ring of Daewoo diesel generator set increases after being cemented or worn by carbon deposition, oil scraping loss, oil return hole of oil ring is blocked by carbon deposition, oil pipe joint or gasket leaks, etc.

The oil ring is coking or worn, the oil ring clearance of Daewoo diesel generator set increases, and the scratches increase. If the oil ring of Daewoo diesel generator set is excessively worn, it must be replaced with a new one. The oil ring return hole is blocked by coking and the coking is removed from the return hole.

In addition, Daewoo diesel generator set oil splashes too much, some enters the combustion chamber, and some discharges blue smoke from the exhaust pipe of Daewoo diesel generator set. The oil quantity shall not exceed that of the upper pipeline of the oil meter, the common fault causes of Daewoo diesel generator set oil pipe joint or gasket oil leakage.

Korean Daewoo generator sets may encounter issues of not charging during charging. This issue may be caused by damaged fuses or rectifier diodes. When the fuse is blown, the power indicator light of the Korean Daewoo generator set charger does not light up. After the rectifier diode is damaged, the power indicator light of the Korean Daewoo generator set charger lights up, but there is no DC output.

Disconnect the charger from the battery and test the voltage between the two output terminals of the charger using a multimeter DC voltage block (50V). Pay attention to the red pen on the positive pole of the charger and the black pen on the negative pole. No voltage output visible. Remove the charger housing and inspect the charging safety core. Found 60A safety core burnt out. After replacement, the charger returned to normal charging and troubleshooting.

These are the reasons and troubleshooting methods for non charging of Daewoo generator set in South Korea, which are explained by Xingguang Company, a professional manufacturer of diesel generator. The company has first-class testing equipment, advanced production processes, and professional manufacturing technology.
