The UK Deep Sea Automatic Controller for Diesel Generator Sets

The automatic controller of the deep-sea DSE7320 diesel generator set is a self starting control module for mains power failure. DSE7320 adds mains power monitoring function on the basis of DSE7310; Used to control electronic fuel injection or non electronic fuel injection and gas engines, providing advanced engine detection and protection functions.

This series of products can be regarded as a perfect example of industrial design, not only with beautiful appearance, excellent performance, and powerful functions, but also with simple and easy to understand panel and menu design that is easy to operate. Improved features include real-time clock to enhance event recording and monitoring; Ethernet communication can reduce monitoring costs; The maintenance function can sound an alarm to remind the operator before a major engine accident occurs. The module includes USB, RS232, and RS485 interfaces, as well as a DSENET port for expansion. Remote monitoring or network monitoring is more convenient and timely. The module includes 12 inputs and 8 outputs, and the program can be set through the panel and PC software suite.

• Equipped with manual/automatic functions

• Equipped with AMF+ATS+communication+expansion functions

• Supports electronic fuel injection or non electronic fuel injection as well as gas engines

• Engine parameters: RPM, oil pressure, water temperature, battery voltage, oil level%, operating hours, number of starts, and charging motor voltage

Generator parameters: frequency, three-phase voltage (L-L, L-N), and three-phase current

• Power parameters: KVA, KW, PF, KVAR, KWh, KVAH, and KVAR

• Commercial power parameters: frequency, three-phase voltage (L-L, L-N)

• Supports 14 languages and displays editable content (including Chinese)

• Polish, German, French, Dutch, American English, Portuguese, Swedish, Thai, Turkish, Spanish, Italian, Spanish (Mexico), Arabic, South African and Chinese

• Alarm classification: pre alarm, electrical trip, and shutdown

• Manually control the fuel pump

• Manually control engine speed (electronic fuel injection engine)

• Preset operating time (the unit needs to be started regularly for maintenance and operation)

• Pre set maintenance cycle function (engine running for 250 hours, requiring replacement of three filters, etc.)

• Software firmware version can be upgraded by oneself (e.g. from version 3.0 to version 5.0)

• Equipped with engine and generator monitoring and protection functions

• Equipped with both RS232 and RS485 communication ports

• Supports Modbus RTU communication protocol

• Equipped with PLC logic function (supporting up to 50 steps)

• Sleep power-saving mode

• Graded load shedding - loading/graded virtual load (load box)

If there is no need to detect the mains power, the mains power detection function can be disabled

• All protection functions can be cancelled

250 event records (with date and time)

Technical parameters of the UK deep-sea automatic controller:

Speed sensor frequency range: 1Hz-10KHz

Voltage range of speed sensor: minimum+/-0.5V (during startup) -70V

Fuel relay output A: 15AmpDC output

Starting electrical output B: 15 Amp DC output

Relay output C and D: 8Amp250V passive contact output

Custom outputs E, F, G, and H: 2Amp DC output

Size specifications: 240mm * 181.1mm * 41.7mm

Panel opening size: 220mm * 160mm
