Warning Signal for Parallel Controller of Zhongzhi HGM9510 Generator Set 2

This article continues to introduce what the warning signals of the parallel controller of the Zhongzhi HGM9510 generator set represent.

17. Power generation phase loss warning

When the power generation phase loss detection is enabled, the controller will issue a warning signal when it detects a power generation phase loss

18. Power generation reverse phase sequence warning

When the reverse phase sequence detection of power generation is enabled, the controller will issue a warning signal when it detects the reverse phase sequence of power generation

19. Power generation switch failure warning

When the controller detects that the power generation switch fails to close or open, or when the input port is not set to the power generation closing state input, the controller issues a warning signal

20. Temperature sensor open circuit

When the controller detects an open circuit in the sensor and a warning is selected for the open circuit action type, the controller emits a warning signal

21. High temperature warning

When the high temperature warning is enabled, the controller sends a warning signal when the temperature value detected by the controller is greater than the set high temperature warning value.

22. Low temperature warning

When the low temperature warning is enabled, the controller sends a warning signal when the temperature value detected by the controller is less than the set low temperature warning value.

23. Open circuit warning for oil pressure sensor

When the controller detects an open circuit in the sensor and a warning is selected for the open circuit action type, the controller emits a warning signal.

24. Low oil pressure warning

When the low oil pressure warning is enabled, the controller will issue a warning alarm signal when the detected oil pressure value is less than the set oil pressure warning value.

25. Open circuit warning for liquid level sensor

When the controller detects an open circuit in the sensor and a warning is selected for the open circuit action type, the controller emits a warning signal.

26. Low liquid level warning

When the low liquid level warning is enabled, the controller will issue a warning alarm signal when the liquid level value detected by the controller is less than the set liquid level warning value.

27. Programmable Sensor 1

When the controller detects an open circuit in the sensor and a warning is selected for the open circuit action type, the controller emits a warning signal.

28. Programmable Sensor 1

When the high warning is enabled, the controller sends a warning signal when the sensor value detected by the controller is greater than the set upper limit warning value.

29. Programmable Sensor 1

When the low warning is enabled, the controller sends a warning signal when the sensor value detected by the controller is less than the set lower limit warning value.

30. Programmable sensor 2 open circuit warning

When the controller detects an open circuit in the sensor and a warning is selected for the open circuit action type, the controller emits a warning signal.

31. Programmable Sensor 2

When the high warning is enabled, the controller sends a warning signal when the sensor value detected by the controller is greater than the set upper limit warning value.

32. Programmable Sensor 2

When the low warning is enabled, the controller sends a warning signal when the sensor value detected by the controller is less than the set lower limit warning value.

33. Input port warning

When the switch input port is selected as user-defined and configured as a warning, the controller will issue a corresponding input port warning signal after the input port is valid.

34. Grounding fault warning

When the grounding fault detection is enabled, the controller sends a warning signal when it detects that the grounding current value is greater than the set threshold and the grounding fault action type is selected as a warning.
