Functions of The Fuchuang GEC6500-4G IOT Generator Set Controller

The characteristic functions of the controller for the Fuchuang GEC6500-4G IOT generator set are as follows:

1. The color LCD display is 480 * 320, with backlight, eight languages (Simplified Chinese, English, etc.) display, touch button operation, and additional shortcut function buttons (such as "Cloud Service" and "Reset") are set;

2. Customizable product QR code; Equipped with cloud buttons, it can connect to WIFI, read fault curves, diagnose faults, and adjust controller parameters using a mobile phone;

3. Equipped with 5VDC power supply and supporting voltage type oil pressure sensors, the quality is more stable than that of resistance type sensors;

4. Match the DPF function of National IV diesel engines;

5. Equipped with RS485 communication interface, the "three remote" function can be achieved using MODBUS protocol;

6. Suitable for three-phase four wire, single-phase two wire, two-phase three wire (120/240V) power supply 50/60Hz system;

7. Collect and display three-phase voltage, three-phase current, frequency, and power parameters for power generation/supply;

8. Commercial power has overvoltage, undervoltage, and phase loss functions, while power generation has overvoltage, undervoltage, overclocking, underfrequency, overcurrent, and overpowering functions;

9. Three fixed analog sensors (water temperature, oil pressure, liquid level);

10. Accurately collect various parameters of the engine;

11. Control and protection functions: realize automatic start/stop, closing/opening (ATS switching), and complete fault display protection of diesel generator sets;

12. The module is equipped with four programmable relay outputs, which can be used for power on shutdown, idle control, preheating control, and speed control. One of them is an active output, and the other three are passive contacts, making the configuration more flexible;

13. Equipped with custom input/output port function configuration, different configurations can be selected according to the application scenario;

14. Multiple temperature, pressure, and oil level sensor curves can be directly used and parameters can be customized;

15. Built in WiFi module, which can be used to adjust parameters, upload various data and fault curves through a mobile app;

16. It has maintenance function, and the maintenance type can be selected as date or running time. The maintenance action can be set (invalid, warning or alarm shutdown);

17. Multiple startup success conditions (speed sensor, power generation, oil pressure) can be selected;

18. Built in Yunmao, realizing remote real-time monitoring, remote startup/shutdown, remote parameter tuning and other functions of the unit;

19. Provide multiple cloud service functions: unit repair reporting, fault diagnosis, and remote parameter tuning;
