Steps for Replacing The Oil Water Separator of Yuchai Generator

The Yuchai generator oil-water separator is composed of a hand pressed membrane pump, a liquid level sensor, a float, a housing, and a cover. It is generally installed between the fuel tank and the oil delivery pump to filter out some impurities and moisture in the diesel. It plays an important role in ensuring the fuel efficiency of the Yuchai diesel generator set. In order to allow users to use the diesel generator set safely and confidently, the Yuchai generator is usually equipped with an oil-water separator before leaving the factory. However, any equipment that has been used for a long time will be damaged and need to be replaced. Below, Dingbo Electric will introduce the correct replacement steps for the Yuchai generator oil-water separator for your reference.

1. Open the drain valve and release a portion of the fuel.

2. Use a belt wrench to remove the filter element and the water cup together, and then remove the water cup from the filter element. Both the filter element and the water cup have standard right-hand threads, so they can be removed counterclockwise.

3. Clean the water cup and oil ring.

4. Apply a thin layer of oil to the oil ring with grease or fuel, install a new filter element on the water cup, and then tighten it by hand.

Attention: To avoid damaging the water accumulation cup and filter element, please do not use tools when tightening.

5. Apply a thin layer of oil to the top oil ring of the filter element with grease or fuel, install the water cup and filter element together into the joint, and tighten them by hand.

6. To eliminate air in the filter element, use a starting oil pump to add oil at the top of the filter until oil seeps out of the filter.

7. Start the Yuchai diesel generator set and check for leaks. If there are, stop and troubleshoot.

The user manual of Yuchai generator suggests that the oil-water separator needs to be replaced every 800 hours (or about half a year) of operation, depending on the situation. The above seven steps are the correct replacement steps for the Yuchai generator oil-water separator, hoping to be helpful to you
