Technical Parameters of Control Screen for 80kw Diesel Generator

The main purpose of the generator set control screen is to distribute the electrical energy output by the generator to the user's load or electrical equipment, and also to indicate the operation of the diesel generator and maintain the voltage stability of the generator in the event of load changes.

The control screen of the 80kw diesel generator should be a liquid crystal display self starting control screen. Equipped with manual and self start functions (adjustable time from 10 seconds to 50 seconds). With displays of three-phase voltage, frequency, three-phase current, kilowatt hours, power factor, oil pressure, oil temperature, coolant temperature, unit speed, operating hours, battery voltage, etc. The generator set has overspeed alarm and shutdown, low oil pressure alarm and shutdown, high water temperature alarm and shutdown, generator voltage high and low alarm and shutdown, frequency high and low alarm and shutdown, short circuit current and overcurrent protection.

The intelligent controller for an 80kw generator set adopts high-performance computer chips, which can modify the control program and protection parameters of the generator set. It integrates many functions such as measurement, control, protection, and programmable management, fully meeting the automatic control needs of generator users or professional assembly plants for different types of generator sets.

The functional features are as follows:

The controller measures and displays all electrical parameters output by the generator, as well as the engine speed, oil pressure, water temperature, DC power supply voltage, and operating time. Among them, voltage and current are measured using true effective values to ensure more accurate data;

Chinese and English language menu selection, large screen LCD display;

Multiple preset pressure and temperature sensor options with customizable parameters;

User customizable auxiliary control relay output;

The buttons on the controller panel are used to select control mode, start running programs, display data, and modify operating protection parameters. LED indicators are used to indicate the operating mode of the controller and the operating status of the generator set. The LCD displays various measured parameters and status.

The Dingbo series control screen brands include Zhongzhi, Deep Sea, and other brands, all of which have self start and self stop functions. They can detect speed, frequency, voltage, current, oil pressure, water temperature, and fuel level, and display the reasons for generator set shutdown and alarm.
