The Advantages of Fuchuang FPSS7920 Generator Intelligent Terminal

The performance advantages of the intelligent terminal of the Fushchuang FPSS7920 generator set are as follows:

1. Adopting a 32-bit ARM microcontroller and dual chip processing, with high hardware integration, accurate data, and the ability to build a gateway to the cloud;

2. The color liquid crystal screen (LCD) is 480 * 272, with more direct graphical data display. The language options are Chinese and English, and can be operated directly on the interface;

3. The screen protector adopts hard screen acrylic material, which has good wear resistance and scratch resistance performance; Using silicone panels and buttons, it has strong adaptability to high and low temperatures in the environment, effectively waterproof and oil resistant, and uses high elastic material buttons,

4. Better button feel;

5. Equipped with RS485 communication interface, it can be configured separately on the panel for flexible use. The MODBUS protocol can be used to achieve the "three remote" function;

6. Equipped with a CANBUS interface, it can be connected to an electronic fuel injection machine with J1939. It can not only monitor common data of the electronic fuel injection machine (such as water temperature, oil pressure, speed, etc.), but also control speed increase and decrease through the CANBUS interface;

7. Suitable for three-phase four wire, three-phase three wire, single-phase two wire, two-phase three wire 50/60Hz systems; Collect and display three-phase voltage, three-phase current, frequency, and power parameters for mains/power generation;

8. The mains power has functions such as overvoltage, undervoltage, over frequency, under frequency, phase loss, and reverse phase sequence; Power generation has functions such as overvoltage, undervoltage, over frequency, under frequency, overcurrent, overpower, phase loss, and reverse phase sequence;

9. Control and protection functions: achieve automatic start/stop, closing and opening (ATS switching), and complete fault display protection functions for diesel generator sets;

10. Four fixed analog sensors (cooling water temperature, oil temperature, oil pressure, fuel level);

11. Multiple temperature, pressure, and liquid level sensor curves can be directly used, and sensor curves can be customized;

12. Precisely collect various parameters of the engine: temperature, oil pressure, fuel level, speed, battery voltage, charger voltage

13. Accumulated startup time and number of starts, etc; Parameter setting function: allows users to change their parameters and store them in the internal EEPROM memory,

14. It will not be lost even when the system is powered down. Most parameters can be adjusted from the front panel of the intelligent terminal, and all parameters can be adjusted through USB interface on a PC or RS485 interface on a PC;

15. Save 100 alarm history records for easy troubleshooting and analysis;

16. Internally equipped with real-time clock function, and users can calibrate it themselves, and the cloud can also calibrate it automatically;

17. It can calculate the cumulative operating time of the diesel engine and the cumulative electrical energy of the generator, making it convenient to view the operation and usage of the unit;

18. Featuring unique cloud service functions, optional built-in gateway for cloud based data display, cloud based start stop of units, start curve, alarm curve, and convenient maintenance of units;

19. All parameters are digitally adjusted for simpler and clearer use, improving the reliability and stability of the entire machine;

20. Internally integrated charger, can be directly connected to terminals for use, and the system can measure and monitor float charging current;

21. Integrated structural design, flame-retardant ABS shell, plug-in terminal block, onboard installation method, compact structure,

22. Easy installation, waterproof performance can reach IP55;

23. Alternative control box products with high cost-effectiveness, modular functional design, and expandable and detachable functional modules;

24. Highly integrated hardware, reserved wiring harness interfaces, convenient and flexible function expansion, improving installation efficiency and saving installation time;

25. The optional side cabinet installation method can be customized according to the color of the unit, with a beautiful appearance and convenient use.

As a professional diesel generator manufacturer, we always insist on using first-class talents to build a first-class enterprise, create first-class products, create first-class services, and strive to build a first-class domestic enterprise. If you would like to get more information welcome to contact us via sales@dieselgeneratortech.com.
