1500KW Cummins Marathon Containerized Silent Diesel Generator Set 4

This article continues to introduce the technical specifications and quotation of the 1500KW Cummins Shanghai Marathon containerized silent diesel generator set for diesel generator users.

7.2 On-Site Installation, Commissioning, and Testing

.The supplier shall be responsible for providing free assistance and guidance to the construction unit for on-site installation and commissioning. Under the organization of the owner, the supplier shall cooperate and participate in on-site testing work and participate in the confirmation of the acceptance test results. The owner shall provide necessary tools and common materials.

.During the installation period designated by the owner, the supplier shall send experienced technical personnel to the site to provide free on-site services. The technical personnel of the supplier shall assist the owner in checking the installation quality according to the product manufacturing, installation, and operation standards and handle problems that occur during the commissioning and operation process.

.The supplier shall send experienced technical personnel to provide free training for installation and operation personnel. The installation and operation personnel of the owner are also welcome to come to the supplier's factory for learning and training.

7.3 Supervision of Manufacturing

.The supplier shall notify the owner in advance when carrying out the main processes of equipment manufacturing. The owner has the right to conduct on-site supervision, monitoring of tests, acceptance, and other activities at the product manufacturing factory.

.The supplier shall notify the owner one week in advance of activities such as supervision, monitoring of tests, and acceptance. The relevant personnel shall be organized by the owner.

VIII. Quality Assurance

The equipment warranty period is one year after commissioning or 1000 operating hours. During the warranty period, if the equipment is damaged not due to the owner's human factors, the supplier shall be responsible for replacement or repair. The costs within the warranty scope shall be borne by the contractor.

Quotation for 1500KW Cummins Shanghai Marathon Containerized Silent Diesel Generator Set

·Generator Set Name: Containerized Diesel Generator Set

·Voltage: 230/400V, Frequency: 50HZ, Power Factor: 0.8pf

Name of Product Model Standby Power of Generator Set Cummins Engine Marathon Generator

Containerized Diesel Generator Set DBJD1500-1 1875KVA/1500KW KTA50-G15 MP-100-4

II. Configuration Details of 1500KW Cummins Shanghai Marathon Containerized Silent Diesel Generator Set

.Diesel Engine - Chongqing Cummins

.Generator - Shanghai Marathon

.Controller - British Deep Sea DSE7320 with RS485 interface and remote start function.

.Switchgear: Equipped with a 3200A, 3P, ABB draw-out type circuit breaker. Circuit breaker model: E4N 3200 D LSI 3P WMP NST draw-out type. The switchgear is installed inside the containerized generator set box.

.The low-noise box is equipped with a split-type 1000L daily fuel tank.

.The low-noise box is a brand-new standard 40-foot high cube container for sea transportation, with a container certificate. It is designed and modified according to the air intake and exhaust requirements of the generator set during operation.

.Optional Fuel Tank: 3-ton buried fuel tank, size: 4 meters long, 1.2 meters in diameter. Equipped with an explosion-proof oil transfer pump; does not include the pipeline materials from the oil tank to the generator set.

.Generator Set Functions - Self-starting, self-stopping, various alarm and protection functions. Equipped with a 3200A, 3P, ABB draw-out type circuit breaker. Circuit breaker model: E4N 3200 D LSI 3P WMP NST draw-out type

.Generator Set Accessories:

·Brand-new original engine and generator; DEEPSEA (British Deep Sea) fully automatic controller DSE7320; Maintenance-free battery, battery float charging; Silencer, 50-degree Celsius water tank radiator.

Shipped randomly: Random technical materials for the engine and generator, generator set test report, certificate of conformity and other technical materials.

Note: The generator set price is the ex-factory unit price including VAT in RMB. If it needs to be shipped to other places, the freight will be charged according to the actual amount.

Quotation Explanation

.Payment Method: After the contract is signed, pay a 30% deposit, and pay the remaining balance before delivery.

.Delivery Time: 45 days (delivery time will be postponed if it encounters public holidays)

.If you need to visit the company to inspect the generator set for commissioning and acceptance, please notify us one week in advance.

.Issue a 16% VAT invoice.

.Packaging Method: Naked packaging
