Diesel Generator Input Setting Parallel System

Overall, each independent diesel generator in a parallel rack has four to six small powers. If a single generator is produced by different vendors and control relies on simple and advanced innovative combinations, the unpredictability of the device will increase. There are 6 precautions for installing an input parallel system on a diesel generator, as follows:

1. Speed control

Each generator operates at its predetermined speed and frequency. After combining the various generators, the engine speed will enter the total speed of the entire frame.

2. Balance load

The heap used by each engine determines its speed. In a parallel structure, all loads are shared by each generator.

3. Synchronization

It is obvious that the cycle of each engine is consistent with a universal framework. You can also use programs to synchronize devices.

4. Voltage regulation

Because of the engine speed of a generator. The voltage of each component is connected to the voltage of different units in the rack. The voltage setting point of any component is slightly higher than the voltage of different generators in the frame, and it will ultimately withstand the full voltage of the frame. The voltage controllers of each generator are connected to each other through an acceptable cross current framework. The system collects the contribution of each transformer to control each voltage and guides each generator to set the voltage.

5. Unit controller

Introduction to the controller, check the engine and generator parameters for each group. Load control and planned generator continuation/shutdown should also be achieved by accessing more propulsion controllers.

6. Actively relay

Check the legal synchronization, load and voltage adjustment, and power capacity of the activity switch controller.

Each highlight is typically achieved by introducing a small-sized controller into the generator. This is a traditional parallel running framework. Each generator has its own specific controller. Although there are still some ACE controllers representing the framework. For smaller settings, this is not feasible, and in some cases, it can be very significant. Because its quality and cost are very high. Each controller must be introduced so that they can control the operation of each generator. And it must be coordinated with the work of parallel frameworks.

Like traditional and mature parallel frameworks, the same applies to power systems. Because multiple controllers are executing tasks simultaneously. It has had many unsettling impacts, and these frameworks often collapse unpredictably. According to this idea, stable monitoring of reliable power supply is necessary when there is a shortage of electricity. It comes with additional costs and obstacles that need to be overcome.

The problem experience of traditional parallel frameworks cannot be overcome by using cautious control frameworks. When in collaborative parallel connection, each generator only has one computer controller, which can screen and control the above key points. This is a significant improvement in the execution of parallel power devices. Similarly, if a short circuit occurs, simply remove the plug and replace it with an additional device. Organizations need to coordinate engines, so there is no need to deal with the problem of endless hard wiring. Because the number of controllers is less than one base, all communication is computerized. Connect the controller to the computer to check its working status. Pave the way for a simple investigation. The current parallel switching equipment can also be associated with PC and Web for remote inspection. If your company is preparing to configure multiple diesel generators for parallel power generation, we can provide you with high-quality, powerful, and efficient diesel generator sets.

As a professional diesel generator manufacturer, we always insist on using first-class talents to build a first-class enterprise, create first-class products, create first-class services, and strive to build a first-class domestic enterprise. If you would like to get more information welcome to contact us via sales@dieselgeneratortech.com.
