Do You Know The Nuclear Emergency Vehicle Mounted Power Station

The nuclear emergency vehicle-mounted power station integrates diesel generator set, diesel oil tank, power cable and electric cable winch, intelligent remote control system, unit parallel system and output switch and other equipment systems, and is installed on the integrated cabin and vehicle chassis. Realize mobile fast, independent operation, multi-machine parallel expansion, local or remote control. Meet the ultimate guarantee of nuclear power plant to provide power under various extreme conditions. In case of shutdown, loss of external power and breakdown of fixed standby power supply equipment, it can reliably provide sufficient power supply in the shortest time to ensure the safety of nuclear reactor and its equipment. When nuclear leakage occurs, it can be monitored far away from the radiation source, and provide the power required for emergency rescue and recovery of the nuclear power plant under safer conditions.

The power range of a single modular unit is from 30 to 2000 kW, and the voltage range is from 0.4 kV to 10.5 kV according to the current situation of the nuclear power plant.

(1) Remote monitoring is not subject to geographical restrictions and is far away from nuclear radiation sources.

The nuclear emergency vehicle-mounted diesel generator system can provide a variety of communication modes to realize remote operation, monitoring, control, on-site visual image transmission and other functions, and can be operated away from nuclear radiation sources all day without geographical restrictions, to avoid or reduce personal injury to the maximum extent. In case of nuclear leakage accident, it is more necessary to have remote monitoring function. Different monitoring modes can be adopted according to the site conditions.

(2) Mobility and safety.

Due to the modular characteristics of the emergency vehicle-mounted power station, it can be stored in a safe area to reduce the damage of earthquakes, typhoons and tsunamis. Due to the mobility characteristics of the vehicle itself, it can reach the site quickly.

(3) Unlimited capacity expansion of multiple machines in parallel.

The 6000kW diesel generator set currently used in the nuclear power station can use the characteristics of parallel expansion of multiple units in the emergency power supply on-board power station to meet the use requirements. The diesel generator set is a multi-unit parallel system.

The unit, parallel control system and parallel output switch are a module in the system. The modules can be connected quickly through the CANBUS bus which can be directly connected. The electric cable winch and power cable can be matched in the cabin. The cable winch can rotate forward, reverse and stepless speed regulation. The output cable of each unit can be connected to the load as quickly as possible according to A/B/C/N, and then the power can be switched on in parallel to supply power to the load.

(4) Digital intelligent parallel system.

The LCD intelligent master control module is adopted, which integrates the operation, control, protection, parameter display, parallel operation and load distribution of generator sets, and can realize the parallel operation of 32 sets at most.

The parallel system adopts full digital control, and the parallel accuracy is very high. The parallel circulation is less than 1%. It has no contact design, and the failure rate is very low. Only one key operation is required for parallel operation and disconnection, and there is no possibility of misoperation. It also has the functions of parallel connection with load and smooth load transfer.

(5) Seismic performance.

The diesel generator set itself adopts a nuclear-grade seismic structure, and the cabin adopts a nuclear-grade shock absorption system. The cabin and chassis undergo secondary shockproof treatment. The on-board power station itself can resist super strong earthquakes.

(6) Optional personalized lighting.

According to the need of emergency repair, necessary special personalized functions can be added, including high-power lighting, steerable spotlights, etc.

The nuclear emergency mobile power station can effectively solve the problem that fixed diesel generator units are vulnerable to floods, tsunamis and other disasters, and has many features such as remote monitoring without geographical restrictions, flexible and rapid response, multiple machines and unlimited expansion.
