Matching Type of Intelligent Genset Controller

The generator set control panel can be divided into general unit control panel and intelligent control panel. According to the installation and use method, the control panel of the generator set can be divided into integrated type and split type; according to the display mode of the generator set, it can be divided into instrument type and liquid crystal digital type.

The general control panel is more suitable for the operation of the general generator set. The start/stop, power supply/power off, and state adjustment of the unit are all manually operated: the intelligent control panel is more suitable for the operation of the intelligent generator set. Stop, supply/power off, state adjustment, etc. can be done manually or automatically.

According to the installation and use method, the control panel of the intelligent generator set can be divided into one type and one type. The split control panel means that the unit is stored separately from the control panel, and the control system and electrical switches are installed and used in the control panel. The integrated control panel is composed of an automatic control panel and a switch panel. The automatic control panel (installation and operation) is fixed on the top of the generator set with the help of shock-absorbing rubber pads, and the switch panel (installation and use of electric switches) is installed on the side of the generator. .

The control screen can be divided into instrument type and LCD digital type according to the display mode of generator set parameters. With the development of electronic information technology, the control panels equipped by generator set manufacturers are all LCD digital display control panels at this stage. The advantage is the visual inspection of the technical indicators and errors of the unit.

At this stage, the main functional modules of the intelligent generator set control panel in the market are: British Deep Sea (DEEPSEA), Czech Comay (COMAP) Wilson independent control panel, and now different manufacturers have developed their own control systems.

Zhongzhi Chinese LCD display function module, with all function modules and settings of manual control screen, automatic/stop/manual function module, operation delay, shutdown delay; protection function module; overspeed, high water temperature, low oil pressure and other alarms for unsuccessful charging And shut down, equipped with emergency stop button. In summary, the diesel generator set has small displacement, high power and high torque, which can meet the various benefits of the engine supply of the generator set.

A generating set control module, comprising a monitoring function module, a monitoring function module, a programming function module, a mobile phone monitoring function module and a wireless data transmission function module; the monitoring function module and the monitoring function module for detecting the technical indicators of the operation of the generator set and the The mobile phone monitoring function module is connected, the monitoring function module is connected to the host computer, the mobile phone monitoring function module is connected to the remote mobile phone by means of the wireless data transmission function module; the programming function module is connected to the host computer, and the monitoring function module, mobile phone The monitoring function module and its monitoring function module enable the generator set control module to have a strong management capability for the operation of the generator set by connecting various functional modules to the main body of the function module.
