Methods Of Diagnosing Diesel Generator Faults

In case of failure of diesel generator during power supply, keep calm and carry out inspection and analysis step by step and purposefully. Don't rush around blindly and dismantle at random. The fault location shall be found according to the abnormal symptoms, signs, noises, occurrence time and change rules of the fault. First of all, detailed analysis and reasoning are carried out from the principle and structure level, and correct judgment is made to find the cause of failure. In the absence of advanced detection equipment, the direct sense diagnosis method is generally used for fault diagnosis, which can be summarized as: look, listen, touch and smell.

Look: the external characteristics of the diesel generator during operation, such as whether the smoke exhaust of the exhaust pipe is abnormal. Whether the exhaust pipe is red. Check whether the oil color is normal and whether the oil level rises. Check whether the oil drained from the oil pan contains water. Check the fuel system, cooling system and lubrication system for water and oil leakage. Check whether the indication of various instruments of diesel generator is abnormal. Whether the nuts of all moving parts are loose. Whether there is vibration, oscillation, etc. when the diesel generator is running.

Listen: mainly listen to the abnormal noise of the diesel generator during operation, and judge the fault according to the nature and location of the abnormal noise. For example, whether the explosion sound of diesel fuel in the combustion chamber is uniform. Check whether the impact sound of piston, connecting rod and crankshaft of diesel generator is abnormal during operation. Check whether there is abnormal noise in the inlet and exhaust valves and the front gearbox of the diesel generator or the fan bearing and belt drive.

Touch: Touch with your hands. Such as pulsation of high pressure oil pipe and vibration of unit. Check whether the temperature of the oil pipe or oil housing is the same as that indicated by the oil temperature gauge. After starting up, the temperature of the exhaust branch pipe of each cylinder can be quickly tested by hand to see if it is consistent. If a cylinder is obviously too low, it can be considered that the cylinder is not working properly or does not work, but pay attention to avoid scalding.

Smell: diagnose by the smell of the fault location. Check whether the diesel generator has burnt smell during operation. Whether the diesel generator has the smell of burning oil.

The above methods should be applied flexibly according to the characteristics of different faults. Through thinking, analysis and reasoning, the faults should be objectively analyzed to find out the causes of faults and eliminate them.
