Product Reliability of Controller for Fuchuang GEC6500-4G Generator Set

Jul. 18, 2024

The reliability of the control product for the Fuchuang GEC6500-4G generator set is reflected in the following 9 aspects:


generator silent type


1. The screen protector is made of hardware acrylic material, which has better wear resistance and scratch resistance;



2. Adopting silicone panels and buttons, with strong adaptability to high and low temperature environments;



3. All parameters are adjusted digitally, abandoning the conventional analog adjustment method of potentiometers, and improving the reliability and stability of the entire machine;



4. Allow users to modify and set its parameters, which are stored in an external EEPROM and will not be lost in case of system power failure. All parameters of the controller can be set on the front panel or upper computer;



5. BootLoader firmware upgrade function, which can upgrade firmware programs through USB to protect customer rights;



6. The power supply range is wide (8-35) VDC, which can adapt to different starting battery voltages;



7. Modular structure design, flame-retardant ABS shell, pluggable terminal block, embedded installation method, compact structure, easy installation.



8. Working conditions: Temperature: (-30~70) ° C Relative humidity: (20~90)% RH Storage conditions: Temperature: (-30~+80) ° C Protection level: IP55: When a waterproof rubber ring is installed between the controller and the control screen.



IP42: When there is no waterproof rubber ring installed between the controller and the control screen. Insulation strength: Object: Between input/output/power supply Reference standard: IEC688-1992



Test method: AC 1.5KV/1min leakage current 3mA



9. Contains multiple types of alarms and alarm shutdowns to avoid abnormal operation of the unit and protect its safety.



Note: Alarm: When the controller detects an alarm signal, the controller only alarms and does not stop, and the LCD displays the alarm quantity and alarm type. Shutdown alarm: When the controller detects a shutdown alarm signal, it immediately shuts down and disconnects the power generation closing relay signal, causing the load to detach and displaying the alarm type.
