Reliability Check of Perkins Diesel Generator Set Automatic Function

When checking the Perkins diesel generator set, one of the most important contents is the reliability check of the automatic function of the diesel generator set. If there is a problem with the automatic function of the unit, it may not be able to stop automatically when emergency shutdown is required, thus causing some more serious faults. Today Starlight will introduce to you the aspects of reliability inspection of automatic function of diesel generator set.

1. The Perkins diesel generator set shall be able to start automatically after receiving the start command of automatic control or remote control.

2. When the Perkins diesel generating set fails for the third time after the automatic start, the start failure signal shall be sent; When a standby unit is set, the program startup system shall be able to automatically transmit the startup command to another standby unit.

3. The time from the automatic start command to power supply to the load shall not exceed 3min.

4. After the automatic start of the Perkins diesel genset is successful, the first load shall not be less than 50% of the rated load.

5. The unit shall be able to stop automatically after receiving the shutdown command of automatic control or remote control; For the standby units used in conjunction with the mains power grid, when the grid returns to normal, the Perkins diesel generator set shall be able to automatically switch or automatically stop, and its shutdown mode and shutdown delay time shall comply with the product technical conditions.

6. Automatic startup success rate. The success rate of automatic startup shall not be less than 99%.

7. Requirements for no-load voltage setting range. The no-load voltage setting range of the unit shall not be less than 95% - 105% of the rated voltage.

8. Automatic supply function requirements. The Perkins diesel generator set shall be able to automatically charge the starting battery.

9. Automatic protection function requirements. The Perkins diesel generator set shall be protected against phase loss, short circuit (no more than 250KW), overcurrent (no more than 250KW), overspeed, high water temperature and low oil pressure.

When checking the reliability of the automatic function of the Perkins diesel generator set, only those that meet all the above requirements can be considered as qualified and can be put into use. Since the automatic function is more important for the unit, when the above requirements are not met, you must not have the idea that it will not affect the use of the unit. You must repair it in time and put it into use after passing the inspection.
