Weichai Diesel Generator Set 6BT Diesel Engine Accessory Drive

Weichai diesel generator set 6BT diesel engine accessory drive device is driven by the crankshaft and drives fuel pump, air compressor and other components from camshaft gear. Exploded view of fuel pump transmission device, mainly composed of transmission gear, support shaft, housing, oil seal, etc.

The inspection method for accessory drive device of Weichai diesel generator set 6BT diesel engine is as follows:

1. Check the holes in the housing. Bearings or bushings are not allowed to rotate inside the casing. If the bearing has become loose and caused wear on the housing hole, the housing should be scrapped.

2. The grooved side of the thrust gasket shall not be close to the housing on the accessory drive device of Weichai diesel generator set 6BT diesel engine. The contact between the steel back and the cast iron shell will hinder the rotation of the thrust washer. Incorrect installation of the thrust pad will cause excessive wear, increase axial clearance, and premature damage to the fuel pump transmission device.

3. Check the shaft for wear, deformation, or damage. The outer diameter of the shaft should not be worn to less than 33.27mm, and the thrust washer should be replaced if worn or damaged.

4. The surface of the oil seal should be undamaged. Before installing a new oil seal, the surface of the housing hub bushing should be checked for wear, and the bushing should be replaced if necessary.

5. Check the bushing in the housing. If the wear is greater than 33.55mm, it should be removed and scrapped.
