Why The Joint Surface of The Diesel Generator Set Leak Oil?

Nowadays, the price of diesel remains high, and the cost of using it for power generation is gradually increasing. Once there is an oil leakage problem, the consumption of diesel will increase again. Therefore, in order to reduce costs and improve the stability of diesel generator sets, it is necessary to correct the leakage The oil problem needs to be solved reasonably, especially the oil leakage problem on the joint surface of the diesel generator set. Why is the joint surface easy to leak oil? There are mainly the following reasons.

1. The quality of the purchased or self-made paper pads is not satisfactory, such as insufficient thickness, improper storage, wrinkled deformation, or careless cleaning during assembly, and dust and impurities, which are the reasons for oil leakage.

2. The oil pressure is too high, which also causes oil leakage on the static joint surface.

3. The quality of the static joint itself is mainly determined by the precision of the processing equipment itself and the storage and transportation conditions. If the precision of the equipment is high, the flatness and roughness of the static joint surface can meet the design requirements of the drawing, and attention should be paid to preventing bumps during storage and transportation, so that it is not difficult to achieve complete sealing of the static joint surface. However, due to the low equipment precision and craftsmanship level of some manufacturers, the storage and transportation conditions and management level cannot fully guarantee that there will be no bumps and scratches.

4. Poor operation skills during maintenance. At present, diesel generator sets are generally based on self-repair. Due to the lack of repair technology, there are often problems of one kind or another in self-repair. Oil leaks due to deformation of parts. At present, the general disassembly method is to use the main bearing seat cover mounting bolts, screw them into the diagonal disassembly screw holes on the main bearing seat cover, and push out the main bearing seat cover. It is difficult to synchronize the progress of the two bolts during the disassembly and assembly process, which is the main reason for the deformation of the main bearing housing cover.

What measures can be taken to prevent it? Starlight power generation equipment is summarized for you as follows:

1. The use of sealing adhesive can seal, prevent leakage, tighten and block gaps, and achieve the purpose of preventing oil leakage.

2. The synchronous operation method should be adopted during the disassembly process. If two people operate at the same time, try to turn the bolts evenly.

3. Use the puller as much as possible where possible to fundamentally solve the synchronization problem.

Starlight Power has advanced testing equipment, modern production technology, professional manufacturing technology, perfect quality management system, and strong technical research and development capabilities. It can provide 3KW～2500KW various specifications of ordinary, automatic, four protection, automatic switching, low noise and mobile generator sets, high quality and low energy consumption to meet the diverse power needs of customers, and can also meet users with different voltages and different frequencies. It is required to create a parallel power supply system for multiple units. If you are interested in our product or any question on generator, welcome to send email to sales@dieselgeneratortech.com.
