How Does The Generator Low-noise Cabinet Reduce Noise?

Regarding the question of how to reduce the noise of the generator's low-noise cabinet, it is necessary to know that noise has a great impact on human health, and when the generator is running, it is accompanied by noise, which seriously affects your health. The noise box can well reduce the impact of noise on users. How does the low-noise cabinet reduce noise, and what is the principle of the internal structure?

The silencing material adopts fireproof, heat-proof, sound-absorbing, wave environmentally friendly sponge plus 0.8mm galvanized iron plate. The perforated plate covers the box sponge to diffuse, absorb, absorb, reduce vibration and reduce noise.

The air intake system is designed on the top of the generator silent box. It is made of galvanized iron plate for turbidity prevention and waterproofing. It is equipped with a partition muffler system and two 25000m3 explosion-proof fans per hour. Forced air intake is used to obtain the air required for the generator to work. Supplement in time. Exhaust air and heat dissipation system, the dirty and waste hot air is discharged in time to ensure that the temperature in the case and the working temperature of the generator will not rise, so as to achieve the purpose of improving power generation efficiency, reducing fuel consumption, and extending the service life of the generator.

Install the KD-KZD series bag-type, medium-efficiency air filter before the air inlet box to make the air entering the box fresh, filter out 90% of the dust above 5 microns in the air, and remove harmful gases dissolved in water in the air. , Keep the indoor air clean, clean and hygienic, and better extend the service life of the air filter element on the unit.

In order to prevent noise from spreading to the air inlet and exhaust system, silencers are installed in the air inlet and exhaust channels and heat dissipation channels. The exhaust pipe is equipped with secondary noise reduction. The muffler achieves the purpose of outdoor noise reduction, and the noise meets the national standard after treatment. . The independent control room provides a good working environment for the operators to work in a noisy environment for a long time and damage their hearing and eyesight. It adopts a vertical operation without noise, and is equipped with a 1.0-hp air conditioner and a data storage place. Better improve the applicability of operators.

The inlet and exhaust air automatically shuts off the system. If the methane content in the cabinet, the flue gas is higher than the standard, or the fire occurs in the cabinet, the flue gas alarm system is used to automatically close the air inlet and exhaust system to cut off the air intake in the generator box and control In the absence of oxygen, the generator cannot run, which better protects the safety of the generator.
