How to Prevent Lightning Damage to The Generator Set?

There are most thunderstorms in summer, but the damage caused by thunder and lightning at other times to the generator set is not ruled out. How to prevent thunder and lightning to reduce losses? The generator set manufacturer will give you a detailed explanation.

The lightning protection method of the generator set should mainly be based on the capacity of the generator set, the strength of local lightning activities and the requirements for power supply reliability. Theory and practice have proved that the generator set connected to the overhead transmission line through the transformer, as long as the transformer is reliably protected, generally does not need to take lightning protection measures for the generator set. In the mine area, there is no special overhead direct wiring. For important generator sets, in order to prevent the lightning wave on the high voltage side of the transformer from endangering the insulation of the generator set through the transformer, it is advisable to install a set of magnetic blown arresters on the outgoing line of the generator set.

The generator set directly connected to the overhead distribution line must be protected against lightning, and different lightning protection measures should be taken for the insulation of the generator set according to different conditions in accordance with the provisions of the national standard design code.

The lightning arrester used to protect the high-voltage rotating electric machine generally adopts the magnetic blown arrester, and the arrester should be assembled close to the generator. Under normal circumstances, the arrester can be installed at the outlet of the motor. If there are no more than two generator sets connected to each group of bus bars, or the capacity of a single unit does not exceed 500kw, and the distance from the arrester is no more than 50m, the arrester can also be installed on each group of bus bars.

When the neutral point of the direct-matching motor can be drawn and is not directly grounded, a magnetic blower or ordinary valve-type arrester should be installed on the neutral point. The rated voltage of the arrester should not be lower than the maximum operating phase voltage of the generator set. For the generator set with a line voltage of 6.3kV, FCD-4 or FZ-4 4kV arresters should be used. 10.5kV generator set should use FCD-6 or Fz-6 6kV lightning arrester.
