Classification of Power Distribution Devices for Diesel Generator Sets

Diesel generator set power distribution device is an important part of power plants and substations. It is an electrical building composed of switchgear, protection appliances, measuring instruments, busbar devices, etc. and necessary auxiliary equipment according to the requirements of the electrical main wiring scheme. It is used to receive and distribute electrical energy during normal operation; it is used to quickly cut off the faulty part in case of failure. , in order to ensure the safe operation of the non-faulty part.

According to the different characteristics of the diesel generating set power distribution device, there can be different classification methods:

(1) According to the different installation sites, it is mainly divided into indoor power distribution devices and outdoor power distribution devices. The indoor power distribution device is a power distribution device that installs electrical equipment in the house. It has the advantages of small footprint, convenient operation, good maintenance conditions, good equipment operating environment, and is not affected by climatic conditions, but the investment in civil construction is increased. Outdoor power distribution device refers to a power distribution device that installs electrical equipment outside the house. It has the advantages of small civil construction investment and short construction period, but has the disadvantages of large floor space, inconvenient operation, poor maintenance conditions, and the equipment operating environment is greatly affected by climate.

(2) According to the different installation methods, it is mainly divided into prefabricated power distribution devices and complete power distribution devices. The prefabricated power distribution device refers to the power distribution device formed by assembling the electrical equipment on site one by one after the civil construction of the power distribution device is completed. It has the advantages of flexible construction and installation, less investment and less metal consumption, but the installation workload is large and the construction period is long. A complete set of power distribution device refers to a power distribution device formed by manufacturing electrical equipment into an independent switch cabinet (panel) according to the requirements of the main electrical wiring in the manufacturer, and only connecting and fixing it after transporting it to the site. The complete set of power distribution device has the advantages of compact structure, high reliability, small footprint and short construction period, but the metal consumption is large and the cost is high.

(3) According to the different voltage levels, it is mainly divided into basic types such as low-voltage power distribution devices (380/220V), high-voltage power distribution devices (6--220kV) and ultra-high-voltage power distribution devices (330kV and above).
