HGM96XX series genset controllers are used for genset automation and monitor control system of single unit to achieve automatic start/stop, data measure, alarm protection and "three remote" (remote control, remote measuring and remote communication). The controller adopts large liquid crystal display (LCD) and selectable Chinese, English or other languages interface with easy and reliable operation.
For more types, please contact us
Product Code: 6010038
Power Supply: DC (8-35)V
Case Dimensions: 266*182*45 (mm)
Panel Cutout: 214*160(mm)
Operating Temp. : (-25~+70)℃
Weight: 0.95kg
| Function Item | Parameter |
| Display | 4.3 inches TFT-LCD (480*272) |
| Operation Panel | Silicon Rubber |
| Language | Chinese & English & Others |
| Digital Input | 8 |
| Relay Output | 8 |
| Analogue Input | 5 |
| AC System | 1P2W/2P3W/3P3W/3P4W |
| Alternator Voltage | (15~360)V(ph-N) |
| Alternator Frequency | 50/60Hz |
| kW/Amp Detecting & Display | ● |
| Monitor Interface | RS485 |
| Programmable Interface | USB/RS485 |
| CANBUS(1939) | ● |
| RTC & Event Log | ● |
| Scheduled Start Genset | ● |
| Maintenance | ● |
| ULP | ● |
| SMS | ● |
| Ethernet | ● |
| SD Card | ● |
| DC Supply | DC(8～35)V |
| Case Dimensions(mm) | 266*182*45 |
| Panel Cutout(mm) | 214*160 |
| Operating Temp. | (-25~+70)℃ |
